PA series simple CNC bending machine

■ The main technical parameters

■ Main parts supporting manufacturers

■ The purpose of the machine

       The PA series simple CNC bending machine is a machine for bending thin plates. The machine is an integral welding structure. The bending machine is mainly formed by the upper mold. Point the edge with a sharp knife, press the dead edge by the flattening die, and press the arc with the R-mould, such as a door frame. Both the forming mold and the lace mold are directly formed.

■ Product shape and structure         The PA series simple CNC bending machine workbench is composed of a base and a pressing plate, which are placed on a support. The base is composed of a seat shell, a cover plate and a coil.

■ Working slide structure The slider of the PA series simple CNC bending machine is a mold component that can slide perpendicular to the mold opening direction during the mold opening action. When the product structure prevents the mold from being demolded normally, the slider must be used. The material itself has the right hardness, wear resistance, and can withstand movement friction.

■ Hydraulic system The hydraulic system of PA series simple CNC bending machine can change the pressure and increase the force. It is composed of five components: power, execution, control, auxiliary, and hydraulic oil. It is mainly used to transmit power and movement. It has small size, high rigidity and response. Fast, great driving force.

■ Electrical control system The electrical control system of the PA series simple CNC bending machine can operate the equipment through the control loop control system. This loop is the electrical control system, which has the functions of start, stop, signal, measurement, and protection loop.

■ Slider synchronization control The function of the synchronizer transmission slider of the PA series simple CNC bending machine is to push the synchronizer ring (copper ring) into the gear coupling tooth at the beginning of gear shifting, so that the taper hole of the synchronizer ring and the taper shaft of the coupling tooth contact and rub. , So that the copper ring rotates at a specific angle and continues to move in gear, and the slider will be pressed in (synchronizer hub) to complete its task.

■ Backgauge The backgauge of PA series simple CNC bending machine can move smoothly on the linear guide rail, and can also be adjusted up and down, which is convenient, efficient and easy to control.

■ E21 system The PA series simple CNC bending machine E21 system has a high-definition LCD screen that displays programming parameters. The X and Y axes can be manually adjusted as required. The operation is simple. It has a one-key parameter backup and recovery function, and supports multi-step programming. Strict testing for EMC, high and low temperature, vibration, etc., is stable and has a long service life.
