W11 series three-roller bending machine
■ The main technical parameters
■ Main parts supporting manufacturers
■ The purpose of the machine
The W11 series three-roller plate bending machine is mechanically lifted and rotated, and can be separated and reclaimed in the upper stroke. Various special side wheels can be installed according to the requirements of customers to achieve the functions of lifting steel such as angle iron and network pipe.
|
■ Product shape and structure W11 series three-roller plate bending machine is composed of frame body, upper roller, hydraulic system, support roller, lower roller, sensor and electrical system. The frame part is composed of left frame, right frame, base and connecting beam, and the upper roller is composed of , The upper roller, the upper roller drive, three sets of supporting rollers, the upper roller beam, and the bearing body. |
|
■ Working slide structure W11 series three-roller plate bending machine slider is a mold component, which can slide perpendicular to the mold opening direction during the mold opening action. When the product structure prevents the mold from being demolded normally, the slider must be used. The material itself has the right hardness, wear resistance, and can withstand movement friction.
|
|
■ Hydraulic system The sealing device in the hydraulic system of the W11 series three-roller bending machine is generally used to prevent the leakage of the working medium and the intrusion of external dust and foreign objects. The hydraulic system of the plate bending machine plays a sealing role.
|
|
■ Electrical control system The W11 series three-roller plate bending machine can operate the use of the equipment through the control loop control system. This loop is the electrical control system, which has the functions of start, stop, signal, measurement, and protection loops.
|
|
■ Slider synchronization control The function of the synchronizer transmission slider of the W11 series three-roller bending machine is to push the synchronizer ring (copper ring) into the gear coupling tooth at the beginning of the gear shift, so that the taper hole of the synchronizer ring contacts and frictions with the taper shaft of the coupling tooth. , So that the copper ring rotates at a specific angle and continues to move in gear, and the slider will be pressed in (synchronizer hub) to complete its task.
|
|
■ Backgauge The back gauge of W11 series three-roller bending machine can move smoothly on the linear guide rail, and can also be adjusted up and down, which is convenient, efficient, and easy to control.
|
|
■ E21 system The E21 system of the W11 series three-roller bending machine is equipped with a high-definition LCD screen to display programming parameters. The X and Y axes can be manually adjusted as required. The operation is simple. It has the function of one-key backup and recovery of parameters and supports multi-step programming. Strict testing for EMC, high and low temperature, vibration, etc., stable and long service life.
|
