W11S Series Upper Roll Universal Rolling Machine

W11S series upper roller universal bending machine is composed of frame body, upper roller, hydraulic system, support roller, lower roller, sensor and electrical system. The frame part is composed of left frame, right frame, base and connecting beam. The roller consists of an upper roller, an upper roller drive, three sets of supporting rollers, an upper roller beam, and a bearing body.

The slider of W11S series upper roller universal plate bending machine is a mold component, which can slide perpendicular to the mold opening direction during the mold opening action. When the product structure prevents the mold from being demolded normally, the slider must be used. The material itself has the right hardness, wear resistance, and can withstand movement friction.

The sealing device in the hydraulic system of the W11S series upper roll universal bending machine is generally used to prevent the leakage of working medium and the intrusion of external dust and foreign objects. The hydraulic system of the plate bending machine plays a sealing role.

The W11S series upper roll universal bending machine can operate the equipment through the control loop control system. This loop is the electrical control system, which has the functions of start, stop, signal, measurement, and protection loops.

The function of the synchronizer transmission slider of the W11S series upper roll universal bending machine is to push the synchronizer ring (copper ring) into the gear coupling tooth at the beginning of gear shifting, so that the taper hole of the synchronizer ring contacts the taper shaft surface of the coupling tooth , Friction, so that the copper ring rotates a specific angle, continue to move in gear, the slider will be pressed in (synchronizer hub) to complete its task.

The back gauge of W11S series upper roller universal bending machine can move smoothly on the linear guide rail, and can also be adjusted up and down, which is convenient, efficient and easy to control.

The E21 system of the W11S series upper roll universal rolling machine has a high-definition LCD screen, which displays the programming parameters. The X and Y axes can be manually adjusted as required. The operation is simple. It has a one-key parameter backup and recovery function, and supports multi-step programming. , After rigorous testing of EMC, high and low temperature, vibration, etc., it is stable and has a long service life.
