Adjustable Angle Hydraulic Shearing Machine

Release time：2021-03-26 09:07 Pageviews：

The main technical parameters：

Main parts supporting manufacturers：

The purpose of the machine:

Adjustable angle hydraulic angle shearing machine is a kind of equipment for shearing metal plates, which can be adjusted arbitrarily within the angle range of 40°~135° to achieve the ideal state. It is mainly used for cutting metal plates, and is used in automobiles, boats, electrical appliances, cooking utensils, stainless steel products, etc.

Product shape and structure：

The adjustable angle hydraulic angle shearing machine includes angle shearing, transportation, and control systems. It has a movable head that can move up and down, and a sleeve connected to the movable head. The movable head is arranged in the sleeve and connected to the movable head and can control the up and down movement of the movable head. Connecting rod.

Working slide structure

The adjustable-angle hydraulic angle shearing machine slider is a mold component, which can slide perpendicular to the mold opening direction during the mold opening action. When the product structure prevents the mold from being demolded normally, the slider must be used. The material itself has the right hardness, wear resistance, and can withstand movement friction.

Hydraulic system：

Adjustable angle hydraulic shearing machine adopts hydraulic down transmission type, changing the pressure to increase the force. It is composed of power, execution, control, auxiliary, and hydraulic oil. It is mainly used to transmit power and movement. It has a small size and rigidity. Big, fast response and great driving force.

Electrical control system：

The adjustable-angle hydraulic shearing machine can control the use of equipment through the control circuit control system. This circuit is the electrical control system, which has the functions of start, stop, signal, measurement, and protection circuits.

Slider synchronization control：

The function of the synchronizer transmission slider of the adjustable angle hydraulic shear angle machine is to push the synchronizer ring (copper ring) into the gear coupling tooth at the beginning of the gear shift, so that the taper hole of the synchronizer ring contacts and frictions with the taper shaft of the coupling tooth. , So that the copper ring rotates at a specific angle and continues to move in gear, and the slider will be pressed in (synchronizer hub) to complete its task.

Backgauge：

The back gauge of the adjustable angle hydraulic angle shearing machine can move smoothly on the linear guide rail, and can also be adjusted up and down, which is convenient, efficient, and easy to control.

E21 system：

Adjustable angle hydraulic angle shears E21 system with high-definition LCD screen, display programming parameters, X, Y axis can be manually adjusted according to needs, easy to operate, with one-key parameter backup and recovery function, support multi-step programming, Strict testing for EMC, high and low temperature, vibration, etc., stable and long service life.
