QC11K series hydraulic (CNC) guillotine shears

QC12K series hydraulic (CNC) pendulum shears are mainly composed of frame, core part, motor, working table, guide ruler and guard, etc. The frame part is steel welded structural parts, motor, core part, guide ruler, etc. , Workbench and guards are all installed on the rack. The movement is composed of an upper beam and a lower beam. The upper beam is connected by two wall panels by rollers. The roller shafts are equipped with middle rollers, outer rollers and gears.

The slider of QC11K series hydraulic (numerical control) guillotine shears is a mold component, which can slide perpendicular to the mold opening direction during the mold opening action. When the product structure prevents the mold from being demolded normally, the slider must be used. The material itself has the right hardness, wear resistance, and can withstand movement friction.

QC11K series hydraulic (CNC) guillotine shears adopt advanced hydraulic integrated valve block, compact structure, reduce pipeline connections, and improve the reliability and easy maintenance of the system.

QC11K series hydraulic (numerical control) guillotine shears can control the use of equipment through the control loop control system. This loop is the electrical control system, which has the functions of start, stop, signal, measurement, and protection loops.

The function of the synchronizer transmission slider of the QC11K series hydraulic (numerical control) guillotine shears is to push the synchronization ring (copper ring) into the gear coupling teeth at the beginning of gear shifting, so that the taper hole of the synchronization ring and the taper shaft of the coupling teeth Surface contact, friction, so that the copper ring rotates a specific angle, continue to move in gear, the slider will be pressed in (synchronizer gear hub) to complete its task.

The back gauge of QC11K series hydraulic (numerical control) guillotine shears can move smoothly on linear guide rails, and can also be adjusted up and down, which is convenient, efficient, and easy to control.

The E21 system of the QC11K series hydraulic (numerical control) guillotine shears has a high-definition LCD screen and displays programming parameters. The X and Y axes can be manually adjusted as required. The operation is simple and has the function of one-key backup and recovery of parameters. Step-by-step programming, after strict EMC, high and low temperature, vibration and other tests, it is stable and has long service life.
